K2 Summit Rotary Labeler
The K2 Summit Rotary Labeler comes equipped your cut & stack label needs. Being belt driven, the K2 Summit provides a container labeling machine at a low cost, with K2 reliability.
Machine Features:
Learn how the K2 Summit can improve your container labeling efficiencies.
Machine Configurations
720mm Platform: 9, 12, 18, 21, & 24 Container Stations
960mm Platform: 16, 24, 28, & 32 Container Stations
1200mm Platform: 20, 30, & 40 Container Stations
*Custom Pitches Possible upon Request
Optional Labeling Configurations
Hot Glue Cut & Stack
Pressure Sensitive
Features
Belt Driven Bottle Table
10" HMI
Ethernet IP Communications
Automatic Speed Control
Recipe Based Product Selection
Servo Driven Infeed Timing Screw with Integrated Over Torque Sensing
Servo Driven Infeed & Discharge Star Wheels with Integrated Over Torque Sensing
Machine Specifications
Speed Range: 50cpm-1200cpm
Container Sizes: 25mm-165mm
*Larger Containers upon Request
Mechanical Upgrades
Recipe Based Auto Height Adjust System
Low Label LED Light Interconnect
Stainless Steel Splash Guard Under Machine with Semi Seal
Lighted Emergency Stop Push Buttons
LED Light Plant Signaling
Under Machine Work Lighting LED Multi Color (Includes White)
Inspection/Rejection System
Automated Reject Conveyor, 2 Lane, 6', Includes Standard Drive Cross Over
Pneumatic Rejector Only with Encoder Tracking
Stainless Steel Conveyor Motor/Gearbox 1HP
Bypass Conveyor Rail Systeem for Non-Labeled Containers
Sanitary Conveyor Washdown
Sanitary Through Labeler Washdown
Air Rejector (Light Containers)
Reject Tray/Bin Size Configurable Stainless Steel (Includes Bin Limit Full Sensor)
Reject Tray/Bin Reject Verification Sensor
